Specifications (nominal & typical)
Source: current catalog record
Electrical
| On-board charger | Yes |
|---|---|
| Power supply included | Yes |
| AC cord options | EU |
| Output | 13V, 60W |
Interface
| Output cable | 2 wire coil |
|---|---|
| Output connector | 5.5 x 2.5mm 90 degrees |
Confirm every value against the datasheet before you commit a design. Temperature limits, charge parameters and the pinout are on the datasheet.
Documents
Datasheet on request. The current revision for this part is issued by engineering. Ask for it and it comes with the quote.
Need a STEP model, drawing or test data that is not listed? Contact us.
Application notes
From the current catalog
No description published.
