Specifications (nominal & typical)
Source: datasheet Rev 1.3
Charging
| Functions | Charge |
|---|---|
| Packs supported | 8 listed below |
Confirm every value against the datasheet before you commit a design. Temperature limits, charge parameters and the pinout are on the datasheet.
Compatibility
Packs supported
| Pack | Voltage | Capacity | Energy | Configuration | Status |
|---|---|---|---|---|---|
| NH2054HD34 | 14.4 V | 6.8 Ah | 98 Wh | 4S2P | Active |
| NH2054QE34 | 14.4 V | 6.8 Ah | 98 Wh | 4S2P | Active |
| NH2057ED34 | 7.2 V | 13.6 Ah | 98 Wh | 2S4P | Active |
| NH2057HD34 | 7.2 V | 13.6 Ah | 98 Wh | 2S4P | Active |
| NH2057QE34 | 7.2 V | 13.6 Ah | 98 Wh | 2S4P | Active |
| NH3054HD34 | 14.4 V | 6.8 Ah | 98 Wh | 4S2P | Active |
| NH3054QE34 | 14.4 V | 6.8 Ah | 98 Wh | 4S2P | Active |
| NH3057QE34 | 7.2 V | 13.6 Ah | 98 Wh | 2S4P | Active |
Documents
Need a STEP model, drawing or test data that is not listed? Contact us.
